Warmup Cellecta HiDECK Overlay 18 Panel 18mm x 600mm x 1200mm

Warmup Cellecta HiDECK Overlay 18 Panel 18mm x 600mm x 1200mm

Special Price £29.71 Regular Price £42.44
Dual Overlay is a free-floating subfloor for use with the Foil Heater under carpet, vinyl and linoleum floor finishes.
- +
Add to Wish List
Warmup Cellecta HiDECK Overlay 18 Panel 18mm x 600mm x 1200mm is available to buy in increments of 1
Size Guilde Delivery & Return
Delivery

All orders shipped with UPS Express.

Always free shipping for orders over US $250.

All orders are shipped with a UPS tracking number.

Returns

Items returned within 14 days of their original shipment date in same as new condition will be eligible for a full refund or store credit.

Refunds will be charged back to the original form of payment used for purchase.

Customer is responsible for shipping charges when making returns and shipping/handling fees of original purchase is non-refundable.

All sale items are final purchases.

Help

Give us a shout if you have any other questions and/or concerns.

Email:contact@domain.com

Phone: +1 (23) 456 789

Availability:In stock
SKU
WDO-HIDECK18
Brand warmup
Warmup Cellecta HiDECK Overlay 18 Panel 18mm x 600mm x 1200mm
Dual Overlay is a free-floating subfloor for use with the Foil Heater under carpet, vinyl and linoleum floor finishes.

Dual Overlay is a free-floating subfloor for use with the Foil Heater under carpet, vinyl and linoleum floor finishes.

Key features

  • Provides a stable subfloor - On which a variety of floor coverings can be laid
  • Protection for the heating system - Ensures that the entire heating system is protected underneath the finished floor covering.
  • Very thin at only 7mm in depth - Easy to install and minimal impact on floor levels.

What is the Dual Overlay System?

Dual Overlay is recommended for use with Warmup’s Foil Heater and Insulated Underlay for a complete electric underfloor heating solution perfect for softer floor finishes.

The two layers of Dual Overlay sit above the Foil Heater, acting as a strong and stable subfloor that protects the floor heater from heavy load points such as large bookcases or beds. The system is free-floating and quick and easy to install.

Dual Overlay for ‘Dry’ rooms

The Dual Overlay System is not suitable for applications in ‘wet ‘rooms such as bathrooms. If you are using vinyl or carpet in a wet room, consider using compatible electric systems such as the DCM-PRO, StickyMat or Loose Wire systems; all installed with a 10mm layer of self-levelling compound to protect the system from moisture. Please contact Warmup for more information.

Installation

Composed of a separate Top Board and Base Board, the Dual Overlay’s two layers are positioned above one another with staggered and overlapping joints to guarantee a strong subfloor. The system is available for purchase in packs of 4 pairs of boards, offering coverage of 2.88 m2. As a floating subfloor, the Dual Overlay System is not fixed to the floor below and offers a quick, clean installation without the need for screed.

Some floor manufactures only allow the use of underfloor heating systems with their flooring when embedded within a screed/ leveling compound. It is important that you check with the vinyl or carpet manufacturer on the types of underfloor heating systems that are suitable for you chosen floor finish.

Specifications

Thermal resistance0.45 tog
Dimensions18 x 600 x 1200 mm
Coverage0.72 m²
Alternative code (price list p.7)UK-WUK-IN-WDO-HIDECK18
Size1200mm (L) x 600mm (W)
ThicknessBase board – 3mm Top board – 4mm
CompositionMDF, fitted with an interactive adhesive
Density (kg/m³)770
Bending Strength kg/cm²>40
Humidity (%)4-10
Thermal R value (m²K/W)0.047
Fire Class, DIN4102B2
More Information
Price£42.44
Delivery Days2 to 3 Days
FeatureNo
BrandWarmup
Description

Dual Overlay is a free-floating subfloor for use with the Foil Heater under carpet, vinyl and linoleum floor finishes.

Key features

  • Provides a stable subfloor - On which a variety of floor coverings can be laid
  • Protection for the heating system - Ensures that the entire heating system is protected underneath the finished floor covering.
  • Very thin at only 7mm in depth - Easy to install and minimal impact on floor levels.

What is the Dual Overlay System?

Dual Overlay is recommended for use with Warmup’s Foil Heater and Insulated Underlay for a complete electric underfloor heating solution perfect for softer floor finishes.

The two layers of Dual Overlay sit above the Foil Heater, acting as a strong and stable subfloor that protects the floor heater from heavy load points such as large bookcases or beds. The system is free-floating and quick and easy to install.

Dual Overlay for ‘Dry’ rooms

The Dual Overlay System is not suitable for applications in ‘wet ‘rooms such as bathrooms. If you are using vinyl or carpet in a wet room, consider using compatible electric systems such as the DCM-PRO, StickyMat or Loose Wire systems; all installed with a 10mm layer of self-levelling compound to protect the system from moisture. Please contact Warmup for more information.

Installation

Composed of a separate Top Board and Base Board, the Dual Overlay’s two layers are positioned above one another with staggered and overlapping joints to guarantee a strong subfloor. The system is available for purchase in packs of 4 pairs of boards, offering coverage of 2.88 m2. As a floating subfloor, the Dual Overlay System is not fixed to the floor below and offers a quick, clean installation without the need for screed.

Some floor manufactures only allow the use of underfloor heating systems with their flooring when embedded within a screed/ leveling compound. It is important that you check with the vinyl or carpet manufacturer on the types of underfloor heating systems that are suitable for you chosen floor finish.

Specifications

Thermal resistance0.45 tog
Dimensions18 x 600 x 1200 mm
Coverage0.72 m²
Alternative code (price list p.7)UK-WUK-IN-WDO-HIDECK18
Size1200mm (L) x 600mm (W)
ThicknessBase board – 3mm Top board – 4mm
CompositionMDF, fitted with an interactive adhesive
Density (kg/m³)770
Bending Strength kg/cm²>40
Humidity (%)4-10
Thermal R value (m²K/W)0.047
Fire Class, DIN4102B2
